| Lifting capacity t | 2 | 3 | 5 | 10 | 16 | 20 | 25 | 32 |
| Lifting height m | 6-18 | 6-18 | 6-18 | 6-18 | 9-18 | 9-18 | 9-18 | 9-18 |
| Pulley magnification | 1/2 | 1/2 | 1/2 | 2/4 | 1/4 | 1/4 | 1/4 | 1/4 |
| Lifting speed m/min | 8(0.8/8) | 8(0.8/8) | 8(0.8/8) | 7(0.7/7) | 3.5(0.35/3.5) | 4(0.4/4) | 3(0.3/3) | 3(0.3/3) |
| Lifting power kw | 3.0 | 4.5 | 7.5 | 13 | 13 | 4-pole 18.5 | 6-pole 18.5 | 6-pole 18.5 |
| Running speed m/min | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 |
| Operating power kw | 0.37 | 0.37 | 0.75 | 0.75*2 | 0.75*2 | 1.1*2 | 1.5*2 | 2.2*2 |
| Trolley gauge | 700-1000 | 750-1000 | 850-1200 | 1100-1500 | 1200-1600 | 1500-2200 | 1800-2500 | 1800-2500 |
| Control mode | Handle / remote control | Handle / remote control | Handle / remote control | Handle / remote control | Handle / remote control | Handle / remote control | Handle / remote control | Handle / remote control |
| Working level | M3/M4 | M3 | M3/M4 | M3/M4 | M3/M4 | M3/M4 | M3/M4 | M3/M4 |
| Power supply | 3P 380V 50Hz | 3P 380V 50Hz | 3P 380V 50Hz | 3P 380V 50Hz | 3P 380V 50Hz | 3P 380V 50Hz | 3P 380V 50Hz | 3P 380V 50Hz |
