The maximum guaranteed load is 2.5 times the workload limit. The minimum ultimate strength is 4 times the working load limit Color paint or electroplating is available upon request Stainless steel AISI 316 Stainless steel 304 Electric galvanized steel
| ITEM NO. | SIZE (in) | WORKING LOAD LIMIT(Ibs) | DIMENSION(in) | ||||
| H-330 | A-330 | B | E | P | R | ||
| GLM1601-01 | 1/4″ | 2,600 | 3,600 | 0.36 | 0.4 | 0.38 | 1.97 |
| GLM1601-02 | 5/16″ | 3,900 | 5.4 | 0.4 | 0.44 | 0.44 | 2.26 |
| GLM1601-03 | 3/8″ | 5,400 | 7,500 | 0.48 | 0.5 | 0.47 | 2.63 |
| GLM1601-04 | 7/16″ | 7,200 | 10,000 | 0.66 | 0.56 | 0.56 | 2.75 |
| GLM1601-05 | 1/ 2″ | 9,200 | 12,750 | 0.75 | 0.66 | 0.63 | 3.19 |
| GLM1601-06 | 5/8″ | 12,750 | 19,000 | 0.91 | 0.78 | 0.75 | 4.09 |
| GLM1601-07 | 3/4″ | 18,500 | 27,000 | 0.94 | 0.94 | 0.88 | 4.63 |
