• T8 Class high-intensity chain, broken off intensity=800mpa
• GBJ802-86 short link chain lift standard in central
• 4 time safety factor of 2.5 time the test load
• Manufacturing quality alloy steel
• Finish: black(accord your need)
| Size d X p (mm) | Width (mm) | WLL(（t) | MPF min. （kN） | BF min.（kN） | |
| Inside min. W1 | Outside W2 | ||||
| 4×12 | 5 | 13 | 0.5 | 12 | 20.2 |
| 5×15 | 6.25 | 17 | 0.8 | 19 | 31.6 |
| 6×18 | 7.5 | 20 | 1.1 | 27 | 45.4 |
| 6.3×19 | 7.88 | 21 | 1.25 | 30 | 50 |
| 7×21 | 8.75 | 23 | 1.5 | 37 | 61.6 |
| 8×24 | 10 | 26 | 2 | 48 | 80.6 |
| 9×27 | 11.25 | 30 | 2.5 | 61 | 102 |
| 10×30 | 12.5 | 33 | 3.2 | 76 | 126 |
| 13×39 | 16.25 | 43 | 5.4 | 128 | 214 |
| 16×48 | 20.8 | 59.2 | 8 | 201 | 322 |
| 18×54 | 23.4 | 66.6 | 10 | 254 | 407 |
| 20×60 | 26 | 74 | 12.5 | 314 | 503 |
| 22×66 | 28.6 | 81.4 | 15 | 380 | 608 |
| 26×78 | 33.8 | 96.2 | 21.2 | 531 | 849 |
| 32×96 | 41.6 | 118 | 31.5 | 804 | 1290 |
